Double Check Honda Accord Codes

Nov. 28, 2022

While running a DTC check on a 2017 Honda Accord equipped with a 2.4L engine with the i-HDS, P0562 may be found, but with no apparent symptoms and the MIL not illuminated.

Information courtesy of Mitchell 1,

Mike Mavrigian

While running a DTC check on a 2017 Honda Accord equipped with a 2.4L engine with the i-HDS, P0562 may be found, but with no apparent symptoms and the MIL not illuminated.

The DTC P0562 may indicate any of the following concerns - battery condition monitor module power source circuit unexpected voltage; generator motor control module system low voltage; and/or traction motor control module system low voltage.

According to Honda, there’s probably nothing wrong. Simply clear the DTC(s) and recheck by cycling the ignition three times. If the DTC returns, continue with normal system troubleshooting.
