Preventing Power Steering Comebacks

June 27, 2016
This bulletin applies to 1997-2010 Cadillac SRX models. According to GM, an analysis of returned power steering pumps that had been replaced for noise issues, no power assist, no or low pressure and leaking conditions has indicated a high number of “No Trouble Found” results.

This bulletin applies to 1997-2010 Cadillac SRX models. According to GM, an analysis of returned power steering pumps that had been replaced for noise issues, no power assist, no or low pressure and leaking conditions has indicated a high number of “No Trouble Found” results.

GM notes that when attempting to repair a power steering concern, the steering system analyzer should be used to assist the technician in a successful diagnosis.

In addition, extensive warranty analysis has shown that the following situations are all significant root causes of PS pump failures:

  • Improper pulley installation.
  • Re-using the O-rings.
  • Using fluid other than the OE-specified steering fluid.
  • Failure to flush the PS system.

In order to reduce comebacks, GM recommends the following tips for replacing a PS pump:

1. Low or no pressure from the PS pump may be the result of dirty or contaminated fluid, which could cause the pressure relief valve to stop functioning. Using the proper tools, flush and bleed the PS system. Any residual contaminants will result in pump failure.

2. When removing the pulley, use the proper special tools. Because the pulley alignment is critical, distorting the pulley may damage bearings in the new PS pump.

3. Be sure to use only new O-rings included with the new PS pump. The new reservoir O-ring must be lubricated with OE-specific PS fluid prior to installation. Also make sure that the control valve O-ring is in its exact groove position and is not covering the pressure bypass hole.

4. Bleed the system according to the procedures recommended in the service manual.
