Replace RAM Rear Axle to Stop Noise

    June 7, 2023
    This bulletin applies to 2017 RAM 1500 vehicles built on or after Nov. 16, 2016 and on or before Dec. 22, 2016, equipped with a 5.7L engine and 3.92 rear axle ratio. The rear axle may develop a whining noise.
    Chrysler
    Replace the rear axle. If equipped with air suspension, disable the air suspension system and deflate the spring to the reservoir before servicing the rear axle.
    Replace the rear axle. If equipped with air suspension, disable the air suspension system and deflate the spring to the reservoir before servicing the rear axle.

    This bulletin applies to 2017 RAM 1500 vehicles built on or after Nov. 16, 2016 and on or before Dec. 22, 2016, equipped with a 5.7L engine and 3.92 rear axle ratio. The rear axle may develop a whining noise.

    Replace the rear axle. If equipped with air suspension, disable the air suspension system and deflate the spring to the reservoir before servicing the rear axle. New fasteners must be used...do not reuse old fasteners.

    P/N                              PART

    68334753AA............rear axle

    06509206AA...........control arm to axle bolts (four)

    06104720AA.......... control arm to axle nuts (four)

    06104264AA..........track bar to axle bolt (one)

    06511267AA..........track bar to axle nut (one)

    About the Author

    Information courtesy of Mitchell 1

    Information for Technical Service Bulletins comes from ProDemand, Mitchell 1's auto repair information software for domestic and import vehicles. Headquartered in San Diego, Mitchell 1 has provided quality repair information solutions to the automotive industry since 1918.
